1.Program control with infrared automatic detection, compatible with any output machine without wire link. 2.Automatic fast-slow adjusting, step-less speed adjusting. 3.Emergency switch assures Superluck plate converyor no risk at all. 4.Custom-designed for any size.
1.Program control with infrared automatic detection, compatible with any output machine without wire link.
2.Automatic fast-slow adjusting, step-less speed adjusting.
3.Emergency switch assures Superluck plate converyor no risk at all.
4.Custom-designed for any size.
Model SL105Z SL135Z Material Size Max 1050X880 1350X1100 Material Size Min 400 Material thickness 0.15—0.5 Transporting speed 0-3 Height adjustment adjustable Power supply 220V 1φ 50/60Hz 2A Net weight (kg) 85 110 Gross weight (kg) 130 160 Mechanic size（mm） 1580X1150X888 1880X1450X888 Packing size（mm） 12500X1250X1050 1550X1550X1050
Model
SL105Z
SL135Z
Material Size Max
1050X880
1350X1100
Material Size Min
400
Material thickness
0.15—0.5
Transporting speed
0-3
Height adjustment
adjustable
Power supply
220V 1φ 50/60Hz 2A
Net weight (kg)
85
110
Gross weight (kg)
130
160
Mechanic size（mm）
1580X1150X888
1880X1450X888
Packing size（mm）
12500X1250X1050
1550X1550X1050
